Quick Details

  • Place of Origin: Zhejiang, China (Mainland)
  • Brand Name: mingrui
  • Model Number: MR1052-P
  • Usage: Magnetic Sensor
  • Theory: level control
  • Output: Switching Transducer
  • color: blue

Packaging & Delivery

Packaging Details 50set/bag,1000set/carton
Delivery Time Shipped in 2 days after payment



Movement explaination:

A float switch is a device used to sense the level of liquid in a tank.

When the float ball moves along the stem with the water level, the magnet inside the ball will

cause the action of the reed switch inside the stem. And the action of the reed switch will energized

or cut off the circuit, this will send to the control board a signal that the liquid level is at the predetermined

 position, then we will know the condition in the tank.

there are usually two way to use the float switch, to prevent overflow or to prevent dry-fire









Model

 MR1052-P

Installation

Top or bottom perpendicular instal

Mounting dimension

M8

Operating characteristic

N.O/N.C  (optional)

   Material  Specification

        Electrical  Specification

  Physic Specification

Float ball

PP

Contact form

 1A

2A

Min shock: 30G on board

Float body

POM

Max contact rating

10W

50W

Min Vibration: 1.5mm (10-55HZ)

Cap nut

POM

Max switching voltage

100VDC

220VDC

Temp Rating: -10-+85°C

O-ring

Silicon

Max breakdown voltage

200VDC

300VDC

Max pressure: 0.2MPa

E-ring

POM

Max switching current

0.5A

1.5A



Filling

EPOXY(ROHS)

Max carry current

1.0A

3A



Wire

UL1007/UL1015

22AWG /24AWG

Max contact resistance

100Ω

100Ω



Working Life

    100,000,000
