Quick Details

  • Place of Origin: Zhejiang, China (Mainland)
  • Brand Name: lubrication oil pump level sensors
  • Model Number: MR1041-P
  • Usage: Magnetic Sensor
  • Theory: level control
  • Output: Switching Transducer
  • color: black
  • material: glass-filled pp
  • raw material: food-grade
  • size: small size
  • package: carton
  • application: level sensor
  • company profile: manufacturer
  • design: own design
  • place of production: Ningbo
  • installation: easy

Packaging & Delivery

Packaging Details 50set/bag,1000set/carton
Delivery Time 10-15 days after receive the payment

lubrication oil pump level sensors

1.long working life 2.stable performance 3.easy mounting 4.multi points control



Level sensor  MR1041-P

 Movement explaination:When the float ball rises or falls with the liquid to the level of the switch, The magnetic force of magnet which inside of the float ball will cause the reed switch to turn ON. When the float ball move away from the reed switch, the reed switch will turn OFF.

























Model

MR1041-P

Installation

Top or bottom perpendicular instal

Mounting dimension

M8

Operating characteristic

N.O/N.C  (optional)

   Material  Specification

        Electrical  Specification

  Physic Specification

Float ball

PP

Contact form

 1A

2A

Min shock: 30G on board

Float body

POM

Max contact rating

10W

50W

Min Vibration: 1.5mm (10-55HZ)

Cap nut

POM

Max switching voltage

100VDC

220VDC

Temp Rating: -10-+85°C

O-ring

Silicon

Max breakdown voltage

200VDC

300VDC

Max pressure: 0.2MPa

E-ring

POM

Max switching current

0.5A

1.5A



Filling

EPOXY(ROHS)

Max carry current

1.0A

3A



Wire

UL1007/UL1015

22AWG /24AWG

Max contact resistance

100Ω

100Ω



Working Life

    100,000,000






Application

Water fountain,air cindition,humidifier,bathroom equipment,sale machine,oil tank and chemical liquid level control.It will be widely applied in motor vehicles,industrial equipment,agricultural equipment and household appliances in the future.



Package

       Standard plastic bags and cartons, also we can provide customized design for all kinds package.



    Production Line

       Our factory management is in accordance with international 5S standards, strict requirements and supervision of the various production processes.

    Latest Exhibitions

        We attended the Electronica in Germany in Nov 2014, new products have won the praise of many buyers.
